Beschreibung
24‑Port 10G Aggregation‑Switch mit 8× 2.5G RJ45, 16× 10G RJ45 und 2× 25G SFP28. Layer‑3‑Routing, Etherlighting und USP‑RPS‑Backup – ideal als Core/Distribution mit hoher Paketleistung.
- Abmessungen: 442 × 480 × 44 mm (17.4 × 18.9 × 1.7")
- Ports: 8× 2.5G RJ45; 16× 10G RJ45; 2× 25G SFP28
- Formfaktor: 1U Rackmount
- Redundanz: DC Power Backup (USP RPS)
- Layer‑3: DHCP Server/Relay, Inter‑VLAN, Static Routing
- Access Lists: IPv4 256, MAC 256
- Tabellen: MAC 128,000; ARP 128,000; IPv4 Routes 256,000
- Puffer: 8 MB; VLANs: 1,000
- Switching Capacity: 460 Gbps; Non‑Blocking: 230 Gbps
- Forwarding Rate: 342 Mpps
- L2: LACP, STP/RSTP, IGMP Snooping, 802.1X, DHCP Snooping/Guarding
- Sicherheit & QoS: MAC/IP ACLs, Device Isolation, Rate Limit, Flow/Storm Control, Multicast/Broadcast Limit
- Ports: Port Isolation/Mirroring, Jumbo Frames, LLDP‑MED, Voice VLAN, Loop Protection
- Strom: AC/DC intern 200 W; Eingang 100–240 V AC; Max. Verbrauch 150 W
- Management: Ethernet, AR; Display: 1.3" Touchscreen; Etherlighting: Ethernet & SFP28
- Gewicht: 7.2 kg ohne Brackets (7.3 kg mit) | Material: SGCC Stahl | ESD: Luft ±30 kV, Kontakt ±20 kV
- Rack‑Tiefe: 482.6 mm 19" (4‑Post, 600–1,066 mm)
- Umgebung: −5 bis 40 °C; 10–90 % r.F.; LEDs: RPS ✓; NDAA ✓; Zert.: CE, FCC, IC, Anatel
